Machining Lab
Machining Centers
![HAAS VFO - 4 Axis Vertical CNC Machining Center](http://engr.uky.edu/sites/default/files/DSC00860-269x269%402x_0.jpg)
HAAS VFO - 4 Axis Vertical CNC Machining Center
![Mazak QuickTurn 10N ATC M/C CNC Lathe](http://engr.uky.edu/sites/default/files/DSC02278aa-269x269%402x_0.jpg)
Mazak QuickTurn 10N ATC M/C CNC Lathe
![HAAS TL-2 CNC Toolroom Lathe](http://engr.uky.edu/sites/default/files/haas-m1-269x269%402x_0.jpg)
HAAS TL-2 CNC Toolroom Lathe
![HAAS VF2 - 4 Axis Vertical CNC Machining Center](http://engr.uky.edu/sites/default/files/IMG_20170525_135056602_BURST000_COVER_TOP-269x269%402x_0.jpg)
HAAS VF2 - 4 Axis Vertical CNC Machining Center
Coolant/Lubrication Capabilities
- ICEFLY cryogenic machining equipment (sponsored by Air Products, Inc.)
- DMP CryoSystems Cryogenic Chamber
- Uni-MIST continuous spray system for MQL applications (sponsored by Unist, Inc.)
- Two uni-MAX precision delivery systems with solenoid control for MQL applications (sponsored by Unist, Inc.)
![External Cryogenic Cooling](http://engr.uky.edu/sites/default/files/2011-07-21-11.41.36-269x269%402x.jpg)
External Cryogenic Cooling
![Dry Burnishing of Al-7075](http://engr.uky.edu/sites/default/files/burnishing-AL-7075-269x269%402x.jpg)
Dry Burnishing of Al-7075
![Flood Cooling](http://engr.uky.edu/sites/default/files/DSC00139-269x269%402x.jpg)
Flood Cooling
![Cryogenic-MQL Hybrid Burnishing of Ti-6Al-4V (Combined Stream Flow)](http://engr.uky.edu/sites/default/files/hybrid-cryo-mql-combined-stream-flowTi-6Al-4V-burnishing-269x269%402x.jpg)
Cryogenic-MQL Hybrid Burnishing of Ti-6Al-4V (Combined Stream Flow)
![Cryogenic-MQL Hybrid Burnishing of Ti-6Al-4V (Separated Stream Flow)](http://engr.uky.edu/sites/default/files/hybrid-cryo-mql-Ti-6Al-4V-burnishing2-separated-stream-flows-269x269%402x.jpg)
Cryogenic-MQL Hybrid Burnishing of Ti-6Al-4V (Separated Stream Flow)
![DMP Cryotemper - Cryogenic Freezer for Pre-cooling Workpieces Before Processing](http://engr.uky.edu/sites/default/files/Machining-Jawahir-3-269x269%402x.jpg)
DMP Cryotemper - Cryogenic Freezer for Pre-cooling Workpieces Before Processing
Accessories/Peripherals
- Two KISTLER 3-Component Tool Dynamometers with Data Acquisition System
- One KISTLER 4-Component Drill Dynamometer with Data Acquisition System
- Acoustic Emission Sensing System
- Infrared Cameras:
- FLIR Systems ThermaCAM PM695
- FLIR Systems SC7650 - KODAK EKTAPRO 1012 (High Speed) Motion Analyzer System
- LA Vision Ultra-High Speed Strain Master Camera System with Microscope
- Six CNC simulators for Turning and Milling
![High-speed Image Capture](http://engr.uky.edu/sites/default/files/DSC00237b-269x269%402x.jpg)
High-speed Image Capture
![DMP Cryotemper - Cryogenic Freezer for Pre-cooling Workpieces Before Processing](http://engr.uky.edu/sites/default/files/DSC00620-269x269%402x.jpg)
DMP Cryotemper - Cryogenic Freezer for Pre-cooling Workpieces Before Processing
![DMP Cryotemper - Cryogenic Freezer for Pre-cooling Workpieces Before Processing](http://engr.uky.edu/sites/default/files/DSC00626-269x269%402x.jpg)
DMP Cryotemper - Cryogenic Freezer for Pre-cooling Workpieces Before Processing
![FLIR SC7650 - Infrared Camera for Thermal Imaging](http://engr.uky.edu/sites/default/files/Machining-Jawahir-1-269x269%402x.jpg)
FLIR SC7650 - Infrared Camera for Thermal Imaging
![Cryogenic Tank for External Liquid Nitrogen Delivery Setup](http://engr.uky.edu/sites/default/files/Machining-Jawahir-5-269x269%402x.jpg)
Cryogenic Tank for External Liquid Nitrogen Delivery Setup
Measuring Instruments
![Nikon Epiphot 300- Optical Microscopy System](http://engr.uky.edu/sites/default/files/DSC00144-269x269%402x.jpg)
Nikon Epiphot 300- Optical Microscopy System
![Zygo NewView 7300 - Scanning White-light Interferometer](http://engr.uky.edu/sites/default/files/Metrology-Jawahir-1-269x269%402x.jpg)
Zygo NewView 7300 - Scanning White-light Interferometer
![Nikon SMZ800 - Optical Microscopy System](http://engr.uky.edu/sites/default/files/Metrology-Jawahir-2-269x269%402x.jpg)
Nikon SMZ800 - Optical Microscopy System
![SUN-TEC - Micro Indentation Hardness Tester](http://engr.uky.edu/sites/default/files/Metrology-Jawahir-4-269x269%402x.jpg)
SUN-TEC - Micro Indentation Hardness Tester
Sample Preparation Tools
![Struers ProntoPress-20 - Hot-mounting System for Metallurgical Samples](http://engr.uky.edu/sites/default/files/DSC00150-269x269%402x.jpg)
Struers ProntoPress-20 - Hot-mounting System for Metallurgical Samples
![Chemical Hood for Etchant Preparation](http://engr.uky.edu/sites/default/files/DSC00151-269x269%402x.jpg)
Chemical Hood for Etchant Preparation
![Struers RotoPol-22 - Mechanical Polishing Equipment](http://engr.uky.edu/sites/default/files/metallo3-269x269%402x.jpg)
Struers RotoPol-22 - Mechanical Polishing Equipment
Other Equipment
![TESA micro-hite 3D - Coordinate-Measuring Machine](http://engr.uky.edu/sites/default/files/DSC01114-269x269%402x.jpg)
TESA micro-hite 3D - Coordinate-Measuring Machine
![Instron 5582 - Mechanical and Material Properties Tester](http://engr.uky.edu/sites/default/files/instron-5582-tensile-fatigue-flexure-mechanical-and-material-testing-269x269%402x.jpg)
Instron 5582 - Mechanical and Material Properties Tester
